Part Number | Common mode Impedance @ 100MHz(Ω) |
DC Resistance (Ω) Max. |
Rated Current (mA) Max. |
Rated Voltage (VDC) | Insulation Resistance (MΩ) Min. | Cutoff Frequency (typ.) (GHz) |
WCM0806Z470SX | 47±20% | 4.0 | 100 | 5 | 100 | 6 |
